50KVA Cummins Diesel Generator Set For Sales BD55C5 manufacturer from China Fujian Bode Power Co., Ltd

50KVA Cummins Diesel Generator Set For Sales

Payment Terms:	T/T,L/C
Place of Origin:	Fujian, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: BD55C5

Production Capacity: 150 pieces/month

Delivery Date: 30days

Brand Name: Cummins

Frequency: 50/60HZ

Means of Transport: Ocean

Packing: Plywood

Output Type: AC Three Phase

Speed: 1500/1800rpm/min

Rated Power: 30kva-450kva

1.Compact structure and mature design
2.Good cooling system
3.LED digital display and modular control
4.Multiple safety Measure

50KVA CUMMINS DIESEL GENERATOR SET BD55C5 / BD66C6 SPECIFICATION

Model	Prime Power	Standby Power	Voltage available
BD55C5(400V/50HZ)	40KW	44KW	380/220v 400/230v 415/240v
PF: 0.8	50KVA	55KVA	380/220v 400/230v415/240v
BD66C6(220V/60HZ)	48KW	53KW	208/120v 220/127v 240/139v
PF: 0.8	60KVA	66KVA	380/220v 440/254v 480/277v

50KVA GENERATOR SET INFORMATION

Diesel Generator Set Model	BD55C5	BD66C6
Motor	Cummins 4B3.9G2
Alternator	STAMFORD OR LEROY SAMER
Speed of control	Electronically
Phase	Three
Fuel Tank Capacity	220LT / 58Galones
System Voltage	24V
Frequency	50HZ	60HZ
Engine coolant flow	1.6L/sec	2.2L/sec
Air intake flow	59L/sec	83L/sec
Exhaust air flow	165L/sec	226L/sec
Exhaust Temperature	540℃	560℃

ENGINE SPECIFICATION FOR 50KVA CUMMINS DIESEL GENERATOR SET
Maximum output(kw)	64KW(50Hz)	74KW(60HZ)	FUEL CONSUMPTION	1500 RPM	1800RPM
Number of Cylinders	4			L/hr	L/hr
Aspiration	Turbocharged		Standby Power	17	19
Cycle	4		Prime Power	15	17
Fuel Type	Diesel		75% Prime Power	11	13
Combustion Type	Direct Injection		50% Prime Power	8	9
Cooling Type	Water cooled
Bore* Stroke	102*120mm		DIMENSION	OPEN	SILENT
Displacement	3.9 L		Length	1850mm	2450mm
Compression Ratio	17.3:1		Width	970mm	1080mm
Lubrication Capacity	9.5 liter		Height	1530mm	1770mm
Coolant Capacity	8.3 liter		Net Weight	1100KG	1490KG

Alternator
Insulation	Class "H"
Excitation Type	Self-excitation or PMG
Protection class	IP23

Certificate

Engine: ISO 3046, BS5514 DIN 6271

Alternator: UTE NFC 51-111-105-110 ICE34-1. BS 5000-4999 NEMA MG21.VDE0503

Generator Set: ISO8525

For other model Cummins Diesel Generator Set, please visit our company web site. Our company is an approved Cummins OEM partner. So we can provide genuine Cummins genset with very competitive price and comprehensive technical support.

Contact us now!
